VS-17R

PRODUCT INFO

17R 350W Moving Head spot beam

Voltage : 110W~240V/50-60Hz
Lamp : Yodn 350W
Color wheel: 13 colors + white
Rotating Gobo Wheel, 12 gobos
Static Gobo wheel,17 gobos,
Prism 1: 8-facet circular prism rotating
Prism 2: 24-facet linear prism rotating
Zoom: parallel beam angel 2.5°-60° change
Frost effect : adjustable Wash effects angle
Focus: linear adjustment
Dimmer : 0-100% linear adjustment
Strobe : Double lens strobe
Pan/Tilt : X axis 540° Y axis 270°
Control mode :DMX512, Automatic and Master/ slave mode
Channel : 16 CHs / 24 CHs/30CHs
Weight : 19kG

Mode/channel			DMX ＆#118alue	Function	Type of control
24	16	30	DMX ＆#118alue	Function	Type of control
1	1	1		Pan
			0-255	Pan movement by 540°	proportional
2	*	2		Pan Fine
			0-255	Fine control of pan movement by 2.11 °	proportional
3	2	3		Tilt
			0-255	Tilt movement by 2 46°	proportional
4	*	4		Tilt Fine
			0-255	Fine control of tilt movement 1°	proportional
5	3	5		Pan/Tilt speed
			0	Max speed	step
				Speed mode
			1-255	Speed from max. to min.	proportional
				Time mode
			1-255	Time from 0.1 sec to 25.5 sec	proportional
6	4	6		Power/Special functions
			0	Empty
				To activate following functions, stop in DMX ＆#118alue for at least 3s and shutter must be closed at least 3s(“Shutter/Strobe” channel 22/15/28 must be at range:0-31 DMX). Corresponding menu items are overwritten temporarily.
			1-24	ECO mode（Lamp power 230W）	step
			25-29	Standard mode（Lamp power 280W）	step

			30-39	Rot. Gobo speed mode	step
			40-49	Rot. Gobo time mode	step
			50-59	Pan/Tilt speed mode	step
			60-69	Pan/Tilt time mode	step

			70-79	Blackout while pan/tilt moving	step
			80-89	Disabled blackout while pan/tilt moving	step
			90-99	Blackout while color wheel moving	step
			100-109	Disabled blackout while color wheel moving	step
			110-119	Blackout while gobo wheel moving	step
			120-129	Disabled Blackout while gobo wheel moving	step
				To activate following functions, stop in DMX ＆#118alue for at least 3 seconds:
			130-139	Lamp On, reset（total reset except pan/tilt）	step
			140-149	Pan/Tilt reset	step
			150-159	Color system reset	step
			160-169	Gobo system reset	step
			170-179	Dimmer/Shutter reset	step
			180-189	Zoom/focus/prism reset	step
			190-199	Reserved
			200-209	Total reset	step
			210-219	Synchronization of random strobe - On
			220-229	Synchronization of random strobe - Off
			230-239	Lamp Off	step


7	5	7		Color wheel
			0-129	Continual positioning	proportional
			130-189	Step Positioning	step
			190-215	Forwards rainbow effect from fast to slow	proportional
			216-217	No rotation	step
			218-243	Backwards rainbow effect from slow to fast	proportional
			244-249	Random color selection by sound control. The sensitivity is from Low to High	step
				(set microphone sensitivity in menu : Run Settings)
			250-255	Auto random color selection from fast to slow	proportional
8	*	8		Color wheel fine positioning
			0-255	Fine positioning	proportional
9	6	9		Rot.Gobo shake
			0	No shake	step
			1-255	Shaking the gobo from slow to fast	proportional
*	*	10		Frost time
			0	Function is off	step
			1-255	Time of frost movement (0.1 sec. to 25.5 sec.)	proportional
*	*	11		Color time
			0	Function is off	step
			1-255	Time of color wheel movement (0.1 sec. to 25.5 sec.)	proportional
*	*	12		Static gobo time
			0	Function is off	step
			1-255	Time of static gobo wheel movement (0.1 sec. to 25.5 sec.)	proportional
*	*	13		Prism time
			0	Function is off	step
			1-50	Time of prism movement (0.1 sec. to 5 sec.)	proportional
			1-255	Time of prism rotation (0.1 sec. to 25.5 sec.)	proportional
*	*	14		Zoom time
			0	Function is off	step
			1-255	Time of zoom movement (0.1 sec. to 25.5 sec.)	proportional
*	*	15		Focus time
			0	Function is off	step
			1-255	Time of focus movement (0.1 sec. to 25.5 sec.)	proportional
10	7	16		Static gobo wheel
			0-54	Gobos with no shake	step
			55-199	Shaking gobos	proportional
			200-201	Open/Hole	step
			202-221	Forward gobo wheel rotation from fast to slow	proportional
			222-223	No rotation
			224-243	backward gobo wheel rotation from slow to fast	proportional
			244-249	Random gobo selection by sound control. The sensitivity is from Low to High	step
				(set microphone sensitivity in menu : Run Settings)
			250-255	Auto random gobo selection from fast to slow	proportional
11	8	17		Rotating gobo wheel
				In the range of 0-59 DMX, the gobo selection speed is controlled by the Effect speed channel 21/*/27
			0-102	Index– set indexing on channel 12/9/18	step
			103-199	Rotation – set rotation on channel 12/9/18
			200-201	Open/hole	step
			202-221	Forward gobo wheel rotation from fast to slow	proportional
			222-223	No rotation	step
,			224-243	Backward gobo wheel rotation from slow to fast	proportional
			244-249	Random gobo selection by sound control. The sensitivity is from Low to High	step
				(set microphone sensitivity in menu : Run Settings)
			250-255	Auto random gobo selection from fast to slow	proportional
12	9	18		Rot. gobo indexing and rotation
				*Gobo indexing – set position on channel 11/8/17*
			0-255	Gobo indexing	proportional
				*Gobo rotation – set position on channel 11/8/17*
			0	No rotation	step
			1-127	Forward gobo rotation from fast to slow	proportional
			128-129	No rotation	step
			130-255	Backward gobo rotation from slow to fast	proportional
13	*	19		Rot. gobo indexing and rotation - fine
			0-255	Fine indexing(rotation)	proportional
14	10	20		Prism
			0-19	Open position (hole)	step
				*Set indexing or rotating on channel 15/11/21*
			20-49	Prism 1 - indexing	step
			50-75	prism 1 - rotating	step
			76-105	Prism 2 - indexing	step
			106-127	prism 2 - rotating	step
			128-191	Double prisms indexing	step
			192-255	Double prisms rotating	step
15	11	21		Prism rotation and indexing
				*Prism indexing – set position on channel 14/10/20*
			0-255	Prism indexing	proportional
				*Prism rotation – set position on channel 14/10/20*
			0	No rotation	step
			1-127	F orward prism rotation from fast to slow	proportional
			128-129	No rotation	step
			130-255	backward prism rotation from slow to fast	proportional
16	12	22		Frost
			0-64	Open	step
			65-255	frost：Area is from small to large	proportional
17	13	23		Zoom
			0-255	Zoom from max. to min beam angle	proportional
18	*	24		Zoom - fine
			0-255	Fine zooming	proportional
19	14	25		Focus
			0-255	Continuous adjustment from far to near	proportional
20	*	26		Focus –fine
			0-255	Fine focusing	proportional
21	*	27		Rot.Gobo speed/Time
				If in speed mode(set in menu)
			0	Max speed	step
			1-255	Speed from fast to slow	proportional
				If in time mode(set in menu)
			0	Function is off	step
			1-255	Time of rot.gobo movement (0.1 sec. to 25.5 sec.)	proportional
22	15	28		Shutter/Strobe
			0-31	Shutter closed（Lamp power reduced to 230W）	step
			32-63	Shutter open ,full lamp power	step
			64-95	Strobe effect from slow to fast	proportional
			96-127	Shutter open	step
			128-143	Opening pulse in sequences from slow to fast	proportional
			144-159	Closing pulse in sequences from fast to slow	proportional
			160-191	Shutter open	step
			192-223	Random strobe effect from slow to fast	proportional
			224-255	Shutter open , full lamp power	step
23	16	29		Dimmer intensity
			0-255	Dimmer intensity from 0% to 100%	proportional
24	*	30		Dimmer intensity – fine
			0-255	Fine dimming	proportional
